Why These Stand Out

✅ True Cat8 Performance
Supports 25Gbps (30m) and 40Gbps (24m).
2000MHz bandwidth - 4× Cat6a capacity.

✅ Military-Grade Shielding
3-stage shielding eliminates alien crosstalk:
Per-pair foil.
85%+ coverage braid.
Conductive RJ45 housing.

✅ Tool-Free Efficiency
90-second termination:
Strip & align wires (T568A/B).
Snap outer shell closed (auto-trims wires).
Engage strain relief collar.

Critical Compatibility Notes

⚠ Cable Requirements:
Must use 22-23AWG Cat8 S/FTP or F/FTP cable
Not compatible with UTP or Cat6a/7 cables

⚠ Channel Certification:
Requires Level III field tester (e.g., Fluke DSX-8000 Cat8)
Full channel must meet TIA-568.2-D Class I

⚠ PoE++ Consideration:
For 90W Type 4, limit to 15m (voltage drop in 22AWG)

Installation Guide

Cable Preparation
✔ Strip 1.75" jacket (preserve drain wire).
✔ Maintain <0.2" untwist on pairs.

Wire Alignment
✔ Use built-in color-coded T568A/B insert.
✔ Fold braid shield over plug body.

Termination
✔ Snap outer cover until "click".

Verify:
✔ All conductors visible in inspection window.
✔ Drain wire contacts metal shell.

Grounding Test
✔ Multimeter check: Shield-to-shield <0.5Ω.
