Why Choose This Customization?

✅ Enhanced Shielding
Foil on each pair + overall braid shield for:
Industrial EMI/RFI protection.
Defense against alien crosstalk in dense bundles.
Groundable shield for PoE safety.

✅ High-Frequency Performance
350MHz bandwidth enables:
2.5GBase-T up to 100m.
5GBase-T up to 50m.
Future-proofing beyond standard Cat5e.

✅ Customization Options
Jacket Types:
PVC (General use).
CMR (Riser-rated for vertical runs).
LSZH (Low-smoke zero-halogen for tunnels).

Lengths: Cut to order (100m min.).
Printing: Custom meter marks/logo printing.

✔ Industrial Automation: Factory floors with motor interference.
✔ Outdoor Wi-Fi: Shielded for lightning-prone areas.
✔ HDBaseT: 4K video over 100m runs.
✔ Retail POS Systems: Dense terminal installations.

Installation Guidelines

✔ Grounding: Terminate to shielded RJ45s/patch panels with proper grounding.
✔ Bend Radius: Minimum 4x cable diameter (≈1" for 24AWG).
✔ Separation: Keep ≥8" from AC power lines.
✔ Testing: Verify:
✔ Shield continuity (≤1Ω resistance).
✔ PS-ANEXT >35dB @ 350MHz.
