Why Choose This Panel?

✅ High-Density 10G Performance
✔ 48 ports in 1RU saves rack space vs traditional panels.
✔ Shielded couplers maintain F/UTP/FTP cable shielding integrity.
✔ Supports 10GBase-T up to 100m (full channel performance).

✅ Professional Shielding System
✔ Metal-shielded couplers with spring-loaded contacts.
✔ Dual grounding paths (panel + individual port shielding).
✔ <1Ω ground continuity when properly installed.

✅ Installation-Optimized Design
✔ Tool-less coupler retention - no screws to lose.
✔ 45° rear cable entry improves bend radius management.
✔ Front labeling slots for port identification.

🔹 For PoE++ Systems: Apply conductive grease to shield contacts to prevent corrosion.
🔹 In IDF Closets: Use color-coded rings (red=uplink, blue=horizontal).
🔹 EMI Troubleshooting: Verify all ports show >85dB shield effectiveness.

Installation Guide

Rack Mounting
✔ Use provided M6 screws (torque to 8 in-lbs).
✔ Connect grounding wire to rack's ground bus.

Cable Termination
✔ Maintain <0.5" untwist on cable pairs.
✔ For shielded cables:
✔ Fold back foil/braid over connector.
✔ Ensure contact with coupler shield.

Grounding Verification
✔ Test shield continuity (port-to-lug) with multimeter.
✔ Resistance should be <1Ω.

Cable Management
✔ Route cables through rear organizer bar.
✔ Maintain 1.5" minimum bend radius.
