The planar optical waveguide (PLC) splitter is an optical power management device made by using quartz substrate optical waveguide technology, which has the characteristics of small volume, high reliability, wide operating wavelength range and good uniformity of splitting. Widely used in PON networks to complete the splitting of optical signals. ARTIC FIBER provides 1xN and 2xN full range of PLC splitter products, and customizes specific applications for customers. All products are in compliance with GR-1209-CORE-2001 and GR-1221-CORE-1999 standards.
Talk to us
✔ High channel counts;
✔ Low excess loss;
✔ Low PDL;
✔ Wide Operatin Wavelength;
✔ High stability and reliability.
✔ Type: Planar Lightwave Circuit (PLC) Splitter;
✔ Configuration: 1x32 (1 input port, 32 output ports);
✔ Connector Type: SC/UPC (Blue connector, Ultra Physical Contact polish);
✔ Housing Material: ABS (Acrylonitrile Butadiene Styrene);
✔ Durable, flame-retardant, and cost-effective enclosure;
✔ Fiber Type: Single-mode (SMF);
✔ Compatible with wavelengths: 1310nm, 1490nm, 1550nm (standard PON wavelengths).
✔ FTTH (Fiber-to-the-Home) Networks;
✔ Used in GPON/EPON/XGSPON systems to distribute signals to multiple subscribers;
✔ Passive Optical Networks (PON);
✔ Splits OLT (Optical Line Terminal) signals to 32 ONT (Optical Network Terminal) units;
✔ CATV & RF Overlay Systems;
✔ Distributes video signals alongside data in hybrid fiber-coaxial networks;
✔ Data Center Interconnects;
✔ Optical signal distribution for monitoring or redundancy.
